CK-A2S Series
High Temperature 2 Socket MIL-Style Connector Kit with PPS Insert, Backshell, and Locking Nut, 392 °F (200 °C) Maximum Temperature
Product Features
- 2 Socket Connection, Crimp Contact
- PPS Locking Ring, No Exposed Metal
- Epoxy Kit (MH109-3D) and Crimp Tool (CB926-1A) Sold Separately
| Specifications | |
|---|---|
| Application | Permanent Mount |
| Max Temperature | 392 °F (200 °C) |
| Connector Type | 2 Socket MIL-Style |
| Shell Material | Polyphenylene Sulfide (PPS) Molded Backshell |
| Connector Insert Material | Polyphenylene Sulfide (PPS) |
| Rating | IP68 |
| Pin-Out | A = Signal (+) Red B = Common (-) Black |
