CK-SFT Series
Triaxial Break Away Safety Connector Kit, Field Installable, 250 °F (121 °C) Max Temp
Product Features
Field Installable Safety feature connector kit
For use with 3/4 conductor cable
| Specifications | |
|---|---|
| Application | Portable Monitoring |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | Safety Feature |
| Shell Material | Nylon |
| Rating | UL94 V-0 |
| Pin-Out | Pin 1: Y Axis (+) Pin 2: X Axis Pin 3: Z Axis (+) Pin 4: Common (-) Pin 5: Shield |
