DSB4000
Dual Input & Output Modular Vibration Switch Box, Stainless Steel Enclosure, NEMA 4X (IP66) Rated, Includes up to 4 DSB-MOD(X) Switch Modules for 8, 16, 24, or 32 Dual Output Sensor Inputs
Product Features
Optional multi-pin connector for interface with on line systems (requires JB931-3A)
Internally earth grounded for noise reduction
- Provides a switched output from up to 32 remotely installed dual output sensors to a data collector through two BNCs, or 3 Pin MIL spec connector
- Modules feature external BNC and 2 or 3 Pin connection options to suit your preferred data collector
- Modular design provides flexible upgrade option
| Specifications | |
|---|---|
| Temperature Range | -58 to 180 °F (-50 to 82 °C) |
| Enclosure Material | Fiberglass |
| Inputs | Terminal Block, 4 Inputs per Channel (A,B,C,GND) |
| Outputs | 2 BNC Jacks and 3 Pin MIL |
| Continuous Output | Optional Multi-Pin Connector for Interface with Online Systems (Requires JB931-3A) |
| Sensor Input Options | 8, 16, 24, 32 |
| Rating | NEMA 4X (IP66) |
| Door Closure | Twist Lock |
| Dimensions | 14.16 x 17.50 x 9.30 in. (360 x 445 x 236 mm) |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
