E2C Series
2 Channel BNC Jack Connector, Polycarbonate Molded, 250 °F (121 °C) Max Temp
Product Features
- 2 BNC Jacks to 1 MultiConductor Cable
- Polycarbonate Molded
- IP66 Rated
| Specifications | |
|---|---|
| Application | Portable Measurements |
| Max Temperature | 250°F (121°C) |
| Connector Type | BNC Jack |
| Strain Relief | Polycarbonate |
| Shell Material | Brass Shell |
| Connector Insert Material | Beryllium copper |
| Rating | IPX6 |
| Pin-Out | Pin = Signal (+) Case = Common (-) |
