EB Series
BNC "E" Style Jack Flange Mount Connector Fastened to Bracket for Low-Cost Installations
Product Features
- Features Cap Cover & Chain for Protection When Not in Use
- 304 Stainless Steel Bracket
- Designed for Low-Cost, Permanent Installations
| Specifications | |
|---|---|
| Application | Permanent Mount |
| Max Temperature | 250 °F (121 °C) |
| Connector Type | Panel Mount BNC Jack |
| Strain Relief | Polycarbonate |
| Shell Material | Nickel-Plated Brass |
| Pin-Out | Pin = Signal (+) Case = Common (-) |
