F2DB Series

2 Channel BNC Plug Connector for Biaxial Accelerometers, Polyurethane Molded, 250 °F (121 °C) Max Temp
A line drawing showing the diameter and length of an assembled CTC F2DB vibration sensor connector kit.
Specifications
Application Portable and Permanent Measurements
Max Temperature 250 °F (121 °C)
Connector Type BNC Plug
Strain Relief Polyurethane
Shell Material Brass Shell
Connector Insert Material Beryllium Copper
Rating IP66
Pin-Out Pin = Signal (+)
Case = Common (-)
Built to Order
