JB220 Standard Size
iBOX Dual Input & Output Vibration Switch Box, Stainless Steel Enclosure, NEMA 4X (IP66) Rated, Sensor Input Options: 4 to 12 Dual Output Sensors
Product Features
Fully featured vibration junction box with IEPE sensor condition indicator lights, and convenient interface with fold-forward panel for easy wiring.
Internally grounded for noise reduction
- Accepts up to 12 dual output sensor inputs for a maximum of 24 channels of measurement
- Includes an IEPE bias indicator light to identify when data is to be collected or to show open and short circuit conditions
- Flip down panel allows for convenient wiring to terminal blocks
| Specifications | |
|---|---|
| Temperature Range | -58 to 180 °F (-50 to 82 °C) |
| Enclosure Material | Fiberglass |
| Inputs | A, B, C, Shield |
| Outputs | 2x BNC Jack and 3 Pin MIL |
| Continuous Output | Multi-Pin Connector for Interface with Online Systems (Optional, Requires JB907-3A) |
| Sensor Input Options | 4, 6, 8, 10, 12 |
| Rating | Nema 4X (IP66) |
| Door Closure | Twist Lock |
| Dimensions | 6.66 x 9.50 x 6.31 in. (169 x 241 x 160 mm) |
| Cord Grips | Optional |
| Switch | 3 Pole |
| Bias Indicator | 1 Channel (A-Signal) |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
