LP262 Datasheet

CE Certification

Product Features

4-20 mA Current Proportional to Vibration in Velocity

Transmit Signals Over Long Distances with No Signal Loss
Outputs to PLC, DCS, SCADA

LP262-XXX-1E

3 Pin Connector

Connector Pin	Polarity
A	(+) Signal/Power
B	(-) Common
C	(+) Temperature Voltage

A drawing showing the dimensions and pin configuration of a CTC LP262 4-20 mA loop power sensor with standard connector.

Built To Order

LP262-XXX-2E

CB105 Integral Cable

Conductor	Polarity
Red	(+) Signal/Power
Black	(-) Common
White	(+) Temperature Voltage
Shield	Cable Drain Wire

A drawing showing the dimensions and pin configuration of a CTC LP262 4-20 mA loop power sensor with integral cable.

Built To Order

LP262-XXX-3E

CB218 Amored Integral Cable

Conductor	Polarity
Red	(+) Signal/Power
Black	(-) Common
White	(+) Temperature Voltage
Shield	Cable Drain Wire

A drawing showing the dimensions and pin configuration of a CTC LP262 4-20 mA loop power sensor with armored integral cable.

Built To Order

Specifications	Standard		Metric
Part Number	LP262		M/ or M8/LP262
Temperature Output		10 mV/°C within the range -40 to 85 °C
Tolerance: 4 mA		(± 10%)
Tolerance: 20 mA		(± 10%)
Tolerance: Temperature		(± 5°C)
Electrical
Settling Time		<30 Seconds
Voltage Source (IEPE)		15-30 VDC
Case Isolation		>10⁸ ohm
Environmental
Operating Temperature Range	-4 to 212 °F		-20 to 100 °C
Sealing		Welded, Hermetic
Submersible Depth	200 ft.		60 m

Specifications	Standard		Metric
Physical
Sensing Element		PZT Ceramic
Sensing Structure		Shear Mode
Weight	3.0 oz		86 grams
Case Material		316L Stainless Steel
Mounting Thread		1/4-28 Blind Tapped Hole
Connector (Non-Integral)		3 Pin MIL-C-5015
Mounting Torque	2 to 5 ft. lbs.		2,7 to 6,8 Nm
Mounting Hardware Supplied	1/4-28 Stud		M6x1 or M8x1.25 Adapter Stud
Calibration Certificate		Current Output @ 100 Hz

Ordering Information

A chart showing configuration options to create a complete part number for ordering a CTC LP262 4-20 mA loop power sensor.
