PMX Series
Vibration Relay & Display System for Single Output Loop Power Sensors, with Option to Include Switch Relay, Fiberglass Enclosure, NEMA 4X (IP65) Rated, Input Options: 1 to 4 Single Output Loop Power Sensors, with Optional Stack Light and Horn Alarm
Product Features
Protect critical machinery & processes from excessive vibration and catastrophic failure
Capability to trigger alarms and shutdown* machinery based on the amplitude of the overall vibration within a selected frequency range to protect critical machinery & processes from excessive vibration & catastrophic failure (*shutdown feature only available when used without the optional stack light)
- Sunlight viewable display of vibration levels: IPS, g's, mils or customized scale
- Relay includes two Form C relays per process controller
- Optional red or tri-color stack light with optional horn alarm can be programmed to flash or remain steadily on when in alert
| Specifications | |
|---|---|
| Temperature Range | 32 to 140 °F (0 to 60 °C) |
| Enclosure Material | Fiberglass |
| Power | 85 to 265 VAC universal power supply |
| Inputs | Up to (4) 4-20 mA Signals |
| Sensor Input Options | Input Options: 1 to 4 Single Output Loop Power Sensors |
| Rating | IP65 |
| Door Closure | Snap Latch |
| Dimensions | 11.90 x 13.77 x 7.40 in (302 x 350 x 188mm) |
| Resistance | Resistant to Hose Directed Fluid |
Ordering Information
