SB202 Extended Capacity
Single Axis Vibration Switch Box, Stainless Steel Enclosure, NEMA 4X (IP66) Rated, Sensor Input Options: 24 to 48 Single Output Sensor Inputs
Product Features
Provides a switched output from remotely installed sensors to a data collector through a BNC and a 2 Pin MIL spec connector
Internally earth grounded for noise reduction
- Accepts inputs from up to 48 Single Axis Sensors
- Built-in online expansion jacks included
- Quick-release input terminal blocks for easy field wiring
| Specifications | |
|---|---|
| Temperature Range | -58 to 180 °F (-50 to 82 °C) |
| Enclosure Material | Stainless Steel |
| Inputs | Terminal Block 3 Inputs per Channel (+, -, Shield) |
| Outputs | BNC Jack and 2 Pin MIL |
| Continuous Output | Multi-Pin Connector for Interface with Online Systems |
| Sensor Input Options | 24, 38, 48 |
| Rating | NEMA 4X (IP66) |
| Door Closure | Twist Latch |
| Dimensions | 14.16 x 17.50 x 9.30 in. (360 x 445 x 236 mm) |
| Cord Grips | Optional |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
