SB252
Single Axis Vibration Switch Box with Continuous Output BNCs, Stainless Steel Enclosure, NEMA 4X (IP66), Sensor Input Options: 6 to 12 Single Output Sensor Inputs
Product Features
Provides a switched output to a data collector, or continuous outputs to a signal recorder or multi-channel analyzer
Internally earth grounded for noise reduction
- Accepts inputs from up to 12 Single Axis Sensors
- Quick-release input terminal blocks for easy field wiring
- BNC jacks for multi-channel output
| Specifications | |
|---|---|
| Temperature Range | -58 to 180 °F (-58 to 82 °C) |
| Enclosure Material | Stainless Steel |
| Inputs | Terminal Block 3 Inputs per Channel (+, -, Shield) |
| Outputs | BNC Jack and 2 Pin MIL |
| Continuous Output | 12 BNC Jacks, Electrically Isolated |
| Sensor Input Options | 6 - 12 Channels |
| Rating | NEMA 4X |
| Door Closure | Twist Latch |
| Dimensions | 6.69 x 8.31 x 4.21 in. (170 x 211 x 107 mm) |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
