SCE310 Series
Fiberglass Enclosure for 1 to 8 CTC Signal Conditioners, NEMA 4X (IP66) Rated
Product Features
Provides 4-20 mA Signals along with dynamic outputs from remotely installed accelerometers to PLC/DCS systems and portable data collectors
Accommodates up to 8 CTC Signal Conditioners factory wired to power supply
- Accepts up to 8 single output sensor inputs for a maximum of 8 channels of measurement
- Includes DC Power Supply with 100-240 VAC Input
- Signal conditioners sold separately
| Specifications | |
|---|---|
| Temperature Range | 15 to 140 °F (-10 to 60 °C) |
| Enclosure Material | Fiberglass |
| Power | 100-240 VAC |
| Inputs | Vibration Input: 1 Input/channel |
| Outputs | BNC Jack for Dynamic Signal and Screw Terminal Blocks for 4-20 mA outputs |
| Sensor Input Options | 1 - 8 Channels |
| Rating | NEMA 4X |
| Door Closure | Twist Latch |
| Dimensions | 16.00 x 17.50 x 8.80 in. (406 x 445 x 224 mm) |
| Cord Grips | Nylon Cord Grips Available |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
