SSB2000
Single Axis Modular Vibration Switch Box, Stainless Steel Enclosure, NEMA 4X (IP66) Rated, Includes SSB-MOD(X) Switch Module for 1 to 12 Single Output Sensor Inputs
Product Features
Enclosure with DIN Rail Mountable Modules for Multiple Inputs and a Switched Output
Internally earth grounded for noise reduction
- Provides a switched output from remotely installed sensors to a data collector through a BNC and a 2 Pin MIL connector
- Accepts inputs from Sensors, Proximity Probes, & Temperature Probes
- Quick-release input terminal blocks
| Specifications | |
|---|---|
| Temperature Range | -58 to 180 °F (-50 to 82 °C) |
| Enclosure Material | Stainless Steel |
| Inputs | Terminal Block 3 Inputs per Channel (+, -, Shield) |
| Outputs | BNC Jack and 2 Pin MIL |
| Continuous Output | Optional Multi-Pin Connector for Interface with Online Systems (Requires JB907-3A) |
| Sensor Input Options | 4, 6, 8, 12 |
| Rating | NEMA 4X (IP66) |
| Door Closure | Twist Lock |
| Dimensions | 6.66 x 9.50 x 6.31 in. (169 x 241 x 160 mm) |
| Cord Grips | Optional |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
