SSB4000
Single Axis Modular Vibration Switch Box, Stainless Steel Enclosure, NEMA 4X (IP66) Rated, Includes up to 4 SSB-MOD(X) Switch Modules for 12 to 48 Single Output Sensor Inputs
Product Features
Enclosure with DIN Rail Mountable Modules for Multiple Inputs and a Switched Output
Internally earth grounded for noise reduction
- Provides a switched output from remotely installed sensors to a data collector through a BNC and a 2 Pin MIL connector
- Accepts inputs from Sensors, Proximity Probes, & Temperature Probes
- Quick-release input terminal blocks
| Specifications | |
|---|---|
| Temperature Range | -58 to 180 °F (-50 to 82 °C) |
| Enclosure Material | Stainless Steel |
| Inputs | Terminal Block 3 Inputs per Channel (+ - Shield) |
| Outputs | BNC Jack and 2 Pin MIL |
| Continuous Output | Optional Multi-Pin connector for Interface with Online Systems (requires JB907-3A) |
| Sensor Input Options | 12, 24, 36, 48 |
| Rating | NEMA 4X (IP66) |
| Door Closure | Twist Latch |
| Dimensions | 14.16 x 17.50 x 9.30 in. (360 x 445 x 236 mm) |
| Cord Grips | Optional |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
