TSB4000
Triaxial Input & Output Modular Vibration Switch Box, Stainless Steel Enclosure, NEMA 4X (IP66) Rated, Includes TSB-MOD12 Switch Module for 1-12 Triaxial Sensor Inputs
Product Features
For interface with CTC-J4 Series Data Collector Cables
Provides a switched output from remotely installed triaxial sensors to a data collector through 3 BNC jacks and 4 Pin connector
- Access up to 12 Triaxial Sensors (36 Measurement Channels)
- Option for Continuous Monitoring Available
- Quick-release input terminal blocks
| Specifications | |
|---|---|
| Temperature Range | -58 to 180 °F (-50 to 82 °C) |
| Enclosure Material | Stainless Steel |
| Inputs | 5 Terminations per Triaxial Sensor (X, Y, Z, COM, GND) |
| Outputs | 3 x BNC Jacks and 1 x 4 Pin Connector |
| Continuous Output | Optional T Plug |
| Sensor Input Options | 12 |
| Rating | NEMA 4X (IP66) |
| Door Closure | Twist Lock |
| Dimensions | 10.00 x 13.50 x 7.22 in. (254 x 343 x 183 mm) |
| Cord Grips | Optional |
| Resistance | Resistant to Hose Directed Fluid and Corrosion |
Ordering Information
