DD100170 Series

8 mm PRO Proximity Probe Driver for Eddy Current Probe, 4-20 mA Output
Specifications
Temperature Range -49ºF (-45ºC) to 189ºF (85ºC)
Enclosure Aluminum
Probe Connector SecureLock
Power & Output Connector 4 Position Terminal Block & BNC
Input Voltage -17.5 to -30 VDC
Linear Range 10-90 mils (0.25 - 2.30 mm)
Nominal Voltage Output -200 mV/mil (-7.87 V/mm)
4-20 mA Output Proportional To Dynamic Displacement
Built to Order

Optional Regulatory Approvals

US & Canada (CSA):
Class I Division 1 Groups A, B, C, D
Class II Division 1 Group E, F, G
Class III
Class I Zone 0 AEx ia IIC
Class I Division 2 Groups A, B, C, D
Class II Division 2 Groups E, F, G
Ex ia IIC Ga
ATEX:
SIRA 16ATEX2084X
Ex ia IIC
International (IECEx):
IECEx CSA 16.0017X
Ex ia IIC
Temperature Codes:
T4 = -45°C to 100°C
T5 = -35°C to 85°C
CSA, ATEX, IECEx Approvals Require Intrinsically Safe Barrier
Driver must be mounted in a NEMA 4x and/or IP6x enclosure
FOR REFERENCE ONLY, PLEASE REFER TO CONTROL DRAWING
